| Printing | |
| Printing method | 9-Pin serial impact printing |
| Printing width | 63.5mm |
| Print Resolution | 84 dpi |
| Printing speed | 4.5 line/s Max. |
| Interface | USB |
| Print paper | 75.5±0.5mm Φ65mm |
| Character size | ANK，Font A: 1.6×3.1mm（9×9 matrix） Font B: 1.2×3.1mm（7×9 matrix）Chinese,traditional Chinese: 2.7×2.7mm（16×16 matrix） |
| Column number | Font A – 33 columns /Font B – 40 columns / Chinese, traditional Chinese – 22 columns |
| Character | |
| Extension character sheet | PC437/Katakana/PC850/PC860/PC863/PC865/WPC1252/PC866/PC852/PC858 |
| Software | |
| Driver | Windows /Linux /Mac |
| Utility | Windows |
| SDK | Windows/ Android |
| Power | |
| Power adaptor | Input：AC 110V/220V, 50～60Hz,
Output: DC 24V/2.5A |
| Printer input | DC 24V/2.5A |
| Cutter | |
| Auto cutter | Partial |
| Physical characteristics | |
| Gross weight | 1.46 KG |
| Dimensions | 230*150*138mm |
| Environmental Requirements | |
| Work environment | 0～45℃, 10～80% RH |
| Storage environment | -10～60℃, 10～90% RH（no condensation） |
| Reliability | |
| Printer head life | 10 Million Lines |
Product Overview
part.1
Black mark orientation, supports invoice printing function
part.2
Support bi-directional printing
part.3
Freshness outstanding design, easy to operate
part.4
GB18030 simplified Chinese, support traditional Chinese and various international languages
part.5
Various interfaces, multiply choices
